Multi-use Woodworking machine, PF16", PF14"

  • Multi-use Woodworking machine, PF16", PF14"
  • Multi-use Woodworking machine, PF16", PF14"
  • Multi-use Woodworking machine, PF16", PF14"
  • Multi-use Woodworking machine, PF16", PF14"
  • Multi-use Woodworking machine, PF16", PF14"
  • Multi-use Woodworking machine, PF16", PF14"
  • Multi-use Woodworking machine, PF16", PF14"
  • Multi-use Woodworking machine, PF16", PF14"
Model No.︰PF16" PF14"
Brand Name︰SHOOT
Country of Origin︰China
Unit Price︰US $ 675 / pic
Minimum Order︰1 pic
Share on:

 Total 35 Related Items
Prev3132333435

Product Description



 Combine Woodworking Machine
Model  PF14"
The machines can do planing,auto planing,left cutting,right cutting,sawing,mortising,cutting,chamfering,slotting,turning,grinding blade,grinding saw blade etc..They are the ideal tools for the carpenters who need multifunction ones.
Max.Planing(autoplaning)Width 360mm
Max.Planing(autoplaning)Depth 3mm
Autoplaning Thickness of Planing Material 6-200mm
Mini.Length of Planing Material 150mm
Auto Feeding Speed 8.5m/min
Spindle Speed 5270r/min
Max.Sawing Thickness 80mm
Motor Power 2.2kw
Overall Dimensions 1600*1610*880
Net Weight 304kg










 Combine Woodworking Machine
Model  PF16"
The machines can do planing,auto planing,left cutting,right cutting,sawing,mortising,cutting,chamfering,slotting,turning,grinding blade,grinding saw blade etc..They are the ideal tools for the carpenters who need multifunction ones.
Max.Planing(autoplaning)Width 400mm
Max.Planing(autoplaning)Depth 3mm
Autoplaning Thickness of Planing Material 6-200mm
Mini.Length of Planing Material 150mm
Auto Feeding Speed 8.5m/min
Spindle Speed 5270r/min
Max.Sawing Thickness 80mm
Motor Power 2.2kw
Overall Dimensions 1600*1610*880
Net Weight 345kg
Packing Size 1600x730x590mm











Export Markets︰Europe,North America,Asia, Middle-east
Payment Details︰T/T,L/C at sight, Western Union
Ship Date︰30days
Standard Met︰CE
