Automatic side sealing machine

QJ-FZ528-C is economy apply the full-automatic side sealing machine of glue two- sidedly.
Style: QJ-FZ528-C

Technical parameter:
Seal the thickness of sideband:0.6-3mm
Seal the height of sideband:12-40mm
Send the speed:5-20m/min
Send the electrical machinery: 1.5KW
Glue post electrical machinery: Apply the glue.
On a lever with an electrical machinery from beginning to end:the frequency conversion of 0.55kw x 2 is adjusted the speed 14000 and rotated/divided.On a lever with one from begginning to end.
Repair the electrical machinery from head to foot: 0.75kw By repairing head to foot.
Polishing electrical machinery: 0.18kw x 2 1400 rotated/divides Upper and lower polishing.
Glue box heater: 2kw
The air presses the side: 0.7mpa
Total power:5.2kw
Size of appearance:4000x1000x1600
Weight:1200kg
Remarks:Shave from head to foot not from head to foot not the precise shave.


The full-automatic side sealing machine of glue two-sidedly
Style: QJ-FZ528-A

Technical parameter:
Seal the thickness of sideband:0.5-3mm
Seal the height of sideband:12-45mm
Send the speed:5-20m/min/give the material automatically
Send the electrical machinery:the frequency conversion of 1.5kw adjusts the speed.
Glue post electrical machinery:the frequency conversion of 0.37kw adjusts the speed/send the area to apply the glue.
On a lever with an electrical machinery from beginning to end:the frequency conversion of 0.55kw x 2 is adjusted the speed 14000 and rotated/divided On a lever with one from begginning to end.
Repair the electrical machinery from head to foot: the frequency conversion of 0.7kw x 2 is adjusted the speed 18000 and rotated /divided By repairing head to foot.
Repair the electrical machinery precisely from head to foot: the frequency conversion of 0.7kw x 2 is adjusted the speed 18000 and rotated /divided Repair precisely from head to foot.
Polishing electrical machinery: 0.18kw x 2 1400 rotated/divides Upper and lower polishing.
Glue box heater: 2kw
The air presses the side: 0.7mpa
Total power:8.3kw
Size of appearance:950x1700x4600
Weight:2000kg
Remarks:Shave the side from head to foot.

This machine seals large-scaler equipment in the side machine, Multiple functional, Can finish the facing straightly type the dysmorphism seals the transport in the side—Apply the glue—Cut off—On a lever with one from beginning to end—From head to foot By repairing—It is repaired that precise from head to foot to the side—Shave the side from head to foot—A great deal of processes, such as polishing, etc.

 Originally adopt and apply the glue device two-sidedly, Make sideband and base material apply the glue evenly. Because this machine adopts And import advanced high quality electric appliance part and imports the electrical machinery, Utilize frequency conversion to control, Enable sending and realizing the stepless speed regulation with the glue axle, Thus got the best speeds of sealing the side of various kinds of panel and satisfactory processing surface.

Applies the full-automatic side sealing machine of glue two-sidely
Style: QJ-FZ528-B

Technical parameter:
Seal the thickness of sideband:0.5-3mm
Seal the height of sideband:12-40mm
Send the speed:16m/min
Send the electrical machinery: 1.1KW
Glue post electrical machinery: Apply the glue.
On a lever with an electrical machinery from beginning to end:the frequency conversion of 0.55kw x 2 is adjusted the speed 14000 and rotated/divided On a lever with one from begginning to end.
Repair the electrical machinery from head to foot: 0.75kw By repairing head to foot.
Polishing electrical machinery: 0.18kw x 2 1400 rotated/divides Upper and lower polishing.
Glue box heater: 2kw
The air presses the side: 0.7mpa
Total power:5.2kw
Size of appearance:950x1600x3600
Weight:1200kg
Remarks:Shave from head to foot not from head to foot not the precise shave.

Applies the semi-automatic side sealing machine of glue two-sidedly
Style: QJ-FZ526-A

Technical parameter:
Seal the thickness of sideband:0.5-3mm
Seal the height of sideband:12-45mm
Send the speed:5-20m/min
Send the electrical machinery:the frequency conversion of 1.1kw adjusts the speed/Give the material automatically
Glue post electrical machinery:the frequency conversion of 0.37kw adjusts the speed/send the area to apply the glue.
Repair the electrical machinery from head to foot: the frequency conversion of 0.7kw x 2 is adjusted the speed 18000 and rotated /divided By repairing head to foot.
Polishing electrical machinery: 0.18kw x 2 1400 rotated/divides Upper and lower polishing.
Glue box heater: 2kw
The air presses the side: 0.7mpa
Total power:5.9kw
Size of appearance:950x1700x3200
Weight:1400kg
Remarks:Shave the side from head to foot.

Applies the semi-automatic side sealing machine of glue two-sidedly
Style: QJ-FZ526-B

Technical parameter:
Seal the thickness of sideband:0.5-3mm
Seal the height of sideband:12-40mm
Send the speed:16m/min
Send the electrical machinery: 1.1kw/Give the material
automatically.
Glue post electrical machinery:the frequency conversion of 0.37kw adjusts the speed/send the area to apply the glue.
Repair the electrical machinery from head to foot: 0.75kw/ By repairing head to foot.
Polishing electrical machinery: 0.18kw x 2 1400 rotated/divides Upper and lower polishing.
Glue box heater: 2kw
The air presses the side: 0.7mpa
Total power:4.5kw
Size of appearance:950x1600x3000
Weight:1000kg
Remarks:It shave from head to foot not from head to foot not the precise shave.

Applies the semi-automatic side sealing machine of glue economly and two-sidedly.

Style: QJ-FZ523-A

Applies the semi-automatic side sealing machine of glue economily and two-sidedly.

Style: QJ-FZ522-A

Technical parameter:
Seal the thickness of sideband:0.5-3mm
Seal the width of sideband:10-45mm
Speed of the conveyer belt:0-20m/min
Power of heating:2kw
Mechanical size:1500x700x1400mm
Mechanical weight:500kg


Seal the side automatically sharply.
Keep material board can manual curve seal the side on rotating.
Frequency conversion is controlled,give the material stepless speed regulation.
